Quick Details
- Condition:New
- Place of Origin:Shandong, China (Mainland)
- Brand Name:GOLDEN
- Model Number:GDKX-500
- Usage:Nuts
- Type:Conveyor Baking Oven
- Power Source:Gas
- Voltage:380~440v
- Power(W):14.6kw
- Weight:6000kgs
- Dimension(L*W*H):7500*2500*2900mm
- Warranty:1 year
- After-sales Service Provided:Engineers available to service machinery overseas
- Material:Stainless Steel
- Driven:China
- Baking Type:Hot Air Circle
- Heating Method:Gas/Electricity
- Roasting Temperature:Automtic Control
- Roasting Time:Automtic Control
- Customized service:Available
Packaging & Delivery
| Packaging Details: | Loaded by Open Top container |
|---|
| Delivery Detail: | 60 working days |
|---|
Description
Multifunctional Continuous Peanut Roaster/Nut Bakers/Cashew Nut
Oven/Sunflower Seed Roaster/Belt Roaster/Pistachio Conveyor
Roaster/Pine Nut Baking Equipment with the capacity 500~2000kg/hr
available
Roasting is a kind of typical key section during food processing,
roasting dries raw material further or cause them to turn brown
color, after roasting, nuts are prepared for packaging and sell,
for blanching, for making paste & butter, for making coated snacks,
candies, and so on.
Multifunctional Continuous Peanut Roaster can dry & roast all kinds
of nuts, granulated snacks, it mainly contains automatic feeding
system, heating device, transferring conveyor, cooling fan and
vibrating discharger. With a recycle conveyor moving, the raw
materials will be fed in, dried & roasted by the hot air evenly,
finally optimized products are obtained at end of roaster with air
temperature. Due to nuts stay on the tray to move forward,
continuous roaster is also called conveyor roasters.
Features
1.It reduces the labor, improves operating efficiency.
2.It has reasonable heat distribution design to circulate the hot
airflow passing though the material both up and down, hence
optimizes the roasting resulting.
3.It is matched with humidity exhausting fan to discharge the
moisture, the fan motor/triangle belt/bearing and mounting base are
durable for long time operation.
4.It has unique cooling system to lead cool air within final
section of peanut roaster, bring the material temperature down to
air temperature.
5.It has facility designed to realize the recirculation of roasting
air, hence decreases the energy consumption.
6.Every door on both sides can be opened for easy cleaning.
7.Different areas are insulated and sealed entirely in order to
make heat loss minimum, and reduce running cost.
Applications:Peanuts, Sunflower Seeds, Pumpkin Seeds, Cashew Nut, Horse Beans,
Almonds, Walnuts, Hazelnut Pistachios, Pine Nuts, Pistachios etc.
Technical Data
Model name | Capacity (KG/Hr) | Voltage (V) | Driven method | Heating method | Noise level (dB) |
Gas | Electricity | Thermic oil |
Continuous Roaster | 500 | 14.6kw/ 380±10V/50HZ | Chain | √ | √ | ------ | ≤75 |
Continuous Roaster | 1000 | 23kw/ 380±10V/50HZ | Chain | √ | √ | ------ | ≤75 |
Continuous Roaster | 2000 | 44kw/ 380±10V/50HZ | Chain | √ | √ | ------ | ≤75 |
Machine Configuration
No. | Description | Brand Name |
1 | ElectricalControl Apparatus | SCHNEIDER(GERMANY) |
2 | Frequency Inverter | DANFOSS(DENMARK) |
3 | Gas Burner | SOOKOOK"MAXI-32(L/R)" (SOUTH KOREA) |
4 | Temperature Controller | SHIMADEN, JAPAN |
5 | Solenoid Valves | DUNGS(GERMANY) |
Customer Visting
Advanced Manufacturing Technology
Shipping Organization
Experienced Installation & Training
