- Peanut butter making machine, mixer for peanut butter, food machine
for sale
Applied range:
ZJR Vacuum Homogeneity Emulsifier are suitable for Cosmetic -face
cream, hand cream, sunscreen cream, eyelash to cream, hair gel,
lotion, bath shampoo, nail polish.
Pharmaceutical industry- ointments, syrup, nutrition, bio-products,
paste of pharmaceutical etc.
Daily use industry-toothpaste, detergents, shoes polish, soap,
fragrance etc
Food industry - sauces, jam, oil,sesame oil, chocolate, butter,
vegetable proteins, animal proteins etc.
Chemical industry-Painting, pigment, dyes, paints, adhesives
detergents etc
Formation:
ZJR Vacuum Emulsifying Mixer Series is composed of emulsification
boiler(fluctuating cover, overturn kettle form or outside circle
form), water boiler, oil water, vacuum system, heating and
temperature control systems, cooling systems, electric machinery
control systems. etc.
Work Elements:
The working elements of ZJR Vacuum Homogeneity Emulsifier are :
After the materials are in the water boiler and oil boiler to
heating & mixing then draw into the emulsification boiler by the
vacuum pump, through the middle(fixed) stirrer & teflon Scrapers
residues stirrer in the emulsification boiler that sweep the
residues on the wall of the boiler, so make the produces of wiped
off become the new interface constantly, then the blade cut off
,compress,fold round,mixing and running to the homogenizer,
according to the high shear wheel and the cutting case to strong
cutting off,impact,Without rules mobility, etc. The material by
cutting in the cut interstices and turn to a particle of 200nm-2um
prompt, because the emulsification boiler is under vacuum state,
the bubble that the supplies produce in the course of mixing is
taken away in time.
Features:
The features of ZJR Vacuum Homogeneity Emulsifier are:
The pot cover is automatic rising type, the material was directed
draw into the emulsifying boiler from oil boiler and water boiler
based on a pipe that is under vacuum, the discharge is based on the
turn the emulsifying boiler. And the heating system is electric
heating or steam heating that the temperature is automation
control. Put the cool water into the intercalated bed so cooling
the material, simple operation and safety( at the outside have a
warm layer). The homogenizer and the blade stirring can together
work or separate work. The material
sliming,emulsification,mixing,dispersing,etc. what will finished
during short time. Contact position adopt high-quality stainless
steel (medical use adopt 316L material make with supplies, the
polishing of surface of the mirror of interior surface, mix the
hygiene of the device in vacuum, it accords with the normal hygiene
standard manufacture of GMP to adopt that is most ideal production
equipment.)
NAME |
| ZJR-250 | ZJR-35O |
Emulsifying pot | Design Volume(L) | 250 | 350 |
Capacity(L) | 200 | 280 |
Scraper Stirring Power(kw) | 2.2 | 2.2 |
Scraper Stirring Speed(rpm) | 0-86 | 0-86 |
Homogenizer r(kw) | 4 | 4 |
Electrical heating power(kw) | 12 | 12 |
Homogenizer speed (rpm) | 2800 | 2800 |
Water pot
| Design Volume(L) | 160 | 250 |
Capacity(L) | 128 | 200 |
power(kw) | 0.75 | 0.75 |
speed(rpm) | 1400 | 1400 |
Electrical heating power(kw) | 8 | 12 |
Oil pot | Design Volume (L) | 130 | 180 |
Capacity (L) | 105 | 150 |
power (kw) | 0.75 | 0.75 |
speed rpm) | 1400 | 1400 |
Electrical heating power (kw) | 8 | 12 |
Dimension:Emulsifying Rack (Length X Width X Height):1850X1105X(2480-3480) /
2000X1350X(2750 -3850)mm
Water boiler and Oil boiler Rack (Length X Width X Height):
1800X768X1600/ 2000X868X1650mm;
Table (Length X Width X Height): 1800X700/2000X750mm
Overall( Length X Width X
Height):2570X1900X(2480-3480)mm/2950X2720X(2750-3850)mm
