Quick Details
- Type:Filling Machine
- Condition:New
- Application:Chemical, Adhesives and sealants
- Packaging Type:tubes
- Packaging Material:aluminum tubes
- Automatic Grade:Semi-Automatic
- Driven Type:Mechanical
- Voltage:220V
- Power:1.1KW
- Place of Origin:Jiangsu, China (Mainland)
- Brand Name:YK
- Model Number:GFG-A
- Dimension(L*W*H):1250*650*1900mm
- Weight:500kg
- Certification:CE,ISO
- After-sales Service Provided:Engineers available to service machinery overseas
- Machine Type:Filling Machine
- Product Type:Sealants
- Filling range:A: 10-75ML, B:50-300ML
- Filling accuracy:±2%
Packaging & Delivery
| Packaging Details: | wooden case |
|---|
| Delivery Detail: | 20-50 working days after payment |
|---|
Specifications
bottle filling and Capping mixing machine
1.For aluminum tubes.Filling and folding.
2.CE & ISO 90001.
3.SS 304 made.
Mayonnaise filling machine,Peanut butter mixer equipment,chili
sauce bottle filling and Capping mixing machine
The machine is specially designed for filling silica gel into
metallic tube and sealing process. The product is featured with
multifuntion of quantity,filling, sealing,printing and packing.
Working Process:
Turn on the power,the filling base automatically rotates into
position.Manually putting tube the base,photoelectric device will
detect the tube and send a signal to filling system.Filling starts
with a quantity pump.Sealing,printing and packing are then
accomplished one by one after filling.
Composition:Filling with high precision by the use of advanced technology. Dual
fold sealing is applied. Phenomena such as bottom leakage etc. are
avoided during the process.Contained unguent is prevented from
solidifying through transportation and storing,It is featured with
easy operation and stepless speed regulation.Quantity,
filling,sealing,printing and ejecting are accomplished continuously
in the process.The Air TAC product are used as pneumatic parts for
the machine. Electric components are composed of domestic Zhengtai
products.
Specification
1.Voltage:AC220V; 50Hz
2.Filling Capacity:10-25 tube/min
3.Filling Quantitu:50-130ml
4.Quantity Error:<2%
5.Tube Size :Dia.25-35mm Length:100~220mm
6.Motor Power:1.1KW
7.Compressed Air:pressure0.6~0.7Mpa
Volume≥0.6m3/min
8.Compressed Nitrogenpressure0.2~0.4Mpa
9.Dimension:1250mm*650mm*1900mm
10.Weight:500kg
Our Services
After-sales service:
1, warranty time: one year, from the date which the product is
qualified commissioning. Any damage except the wrong operation
during warranty period is repaired freely. But buyer should pay for
the airticket, living there charge of our engineer.
2, commissioning services: the product`s installation and
commissioning at the demand side, our engineers will not leave
there untill get your agreement.
3, training services: our engineers will train your staff to
operate it during the period of installation and commissioning, and
they will not leave there untill your staff can operate it properly
and normally.
4, maintenance services: any malfunction happened, once you enquiry
us, we will reply you within 48 hours except the special reasons.
5, lifelong services: we provide lifelong services for all the
products we sold out, and supply the spare parts with discount
price.
6, certificate services: we can provide related certificates to
customers freely according to the request of customers.
7,inspection services: you can ask the third part inspection
company or your inspector to inspect the products before shipment.
8, the file: the Manual Specification, report of the material which
used to the equipment.
